| Item | Specification |
|---|---|
| Specification | Refers To Air-Cooled At Room Temperature 25℃, And The Performance Is Measured According To The Actual Power When Fully Loaded |
| Temperature Range | -70~185℃ 1.0℃ (Heating Slope Nonlinear 0.4℃/S) |
| Temperature Fluctuation | ±0.1°C |
| Plate Distribution Uniformity | ±1°C（Depending On The Plate Size） |
| Minimum Temperature Limit | -70°C |
| Structure | |
| Plate Size | 120 × 50 × 80 mm (W × H × D) |
| Host Size | 350 × 375 × 500 mm (W × H × D) |
| Heat Dissipation Material | Copper / Electroplating |
| Outer Box Material | High-Tensile Steel Plate Paint (White 206 Color) |
| Heating Material | SUS Ø5mm × 70mm，250W × 8 Units |
| Cooling System |
Refrigerant R507/0.5KG; Refrigerant R23/0.8KG Imported Compressor 2 Sets Electronic Expansion Valve 1 Set High-Efficiency Radiator 1 Set Copper Inlet And Outlet High-Pressure Joints 2 Pieces |
| Control System | |
| Control System | 4-Inch Color PLC Temperature Controller |
| Control System |
Touch Panel Data Input Resolution 0.1℃ Temperature Range -70.0℃～+185.0℃ PID Method And Automatic Calculation Function Proportional Band (PB): 1～32767x0.01% Integral Time (IT): 0～32767x100ms Differential Time (DT): 0～32767 x10ms Output Value Display With DIN/PT100Ω Standard Temperature Measuring Input RS-232 Transmission Interface With 9pin Connector |
| Control Switch | Set Of Power Switch |
| Safety Protection Device | |
| Compressor Overcurrent Detectors | 2 Sets |
| Compressor High-Voltage Protectors | 2 Sets |
| Electronic Refrigerant Pressure Detectors | 4 Sets |
| Other | Circuit Fuses And Fully Sheathed Terminals |
| Other Accessories | |
| Temperature Sensor | DIN/PT100Ω Class A Temperature Measuring Sensor × 1 Set |
| Power Cord | Low-Impedance Rubber Power Cord 1.5M × 1 Set |
| Operating Conditions | |
| Performance Guarantee Range | Working Temperature 15~25℃ |
| Power Supply | 1Ø 2W 220V 20A 50~60HZ |
| Power Consumption | 4 KW |
| Warranty Period | Taiwan Area One Year |
